| Manufacturer |
Kamigo Plant
Shimoyama Plant
Deeside Engine Plant
North Plant
Tianjin FAW Toyota Engine’s Plant No. 1 |
| Also called |
Toyota 4A |
| Initial Production |
1982-2002 |
| Cylinder block alloy |
Cast-iron |
| Configuration |
Straight-4 |
| Valvetrain |
SOHC
2 valves per cylinder
DOHC
4 valves per cylinder/5 valves per cylinder |
| Piston stroke, mm (inch) |
77 (3.03) |
| Cylinder bore, mm (inch) |
81 (3.19) |
| Compression ratio |
8
8.9
9
9.3
9.4
9.5
10.3
10.5
11 |
| Displacement |
1587 cc (96.8 cu in) |
| Power output |
58 kW (78 HP) at 5,600 rpm
63 kW (84 HP) at 5,600 rpm
67 kW (90 HP) at 4,800 rpm
71 kW (95 HP) at 6,000 rpm
75 kW (100 HP) at 5,600 rpm
77 kW (105 HP) at 6,000 rpm
81 kW (110 HP) at 6,000 rpm
84 kW (112 HP) at 6,600 rpm
85 kW (115 HP) at 5,800 rpm
92 kW (125 HP) at 7,200 rpm
94 kW (128 HP) at 7,200 rpm
107 kW (145 HP) at 6,400 rpm
116 kW (160 HP) at 7,400 rpm
121 kW (165 HP) at 7,600 rpm
125 kW (170 HP) at 6,400 rpm |
| Torque output |
117 Nm (86 lb·ft) at 2,800 rpm
130 Nm (96 lb·ft) at 3,600 rpm
130 Nm (96 lb·ft) at 3,600 rpm
135 Nm (100 lb·ft) at 3,600 rpm
136 Nm (101 lb·ft) at 3,600 rpm
142 Nm (105 lb·ft) at 3,200 rpm
142 Nm (105 lb·ft) at 4,800 rpm
131 Nm (97 lb·ft) at 4,800 rpm
145 Nm (101 lb·ft) at 4,800 rpm
149 Nm (110 lb·ft) at 4,800 rpm
149 Nm (110 lb·ft) at 4,800 rpm
190 Nm (140 lb·ft) at 4,400 rpm
162 Nm (120 lb·ft) at 5,200 rpm
162 Nm (120 lb·ft) at 5,600 rpm
206 Nm (152 lb·ft) at 4,400 rpm |
| Redline |
– |
| HP per liter |
49.1
52.9
56.7
59.9
63
66.2
69.3
70.6
72.5
78.8
80.7
91.4
100.8
104
107.1 |
| Fuel type |
Gasoline |
| Weight, kg (lbs) |
154 (340) 4AGE |
Fuel consumption, L/100 km (mpg)
-City
-Highway
-Combined |
for Celica GT
10.5 (22.4)
7.9 (29.8)
9.0 (26.1) |
| Turbocharger |
Naturally aspirated,
Toyota SC-12 Supercharger |
Oil consumption, L/1000 km
(qt. per miles) |
up to 1.0
(1 qt. per 750 miles) |
| Recommended engine oil |
5W-30
10W-30
15W-40
20W-50 |
| Engine oil capacity, L (qt.) |
3.0 (3.2) – 4A-FE
3.0 (3.2) – 4A-GE (Corolla, Corolla Sprinter, Marin0, Ceres, Trueno, Levin)
3.2 (3.4) – 4A-L/LC/F
3.3 (3.5) – 4A-FE (Carina 1990-1994, Carina E)
3.7 (3.9) – 4A-GE/GEL |
| Oil change interval, km (miles) |
5,000-10,000
(3,000-6,000) |
| Normal engine operating temperature, °C (F) |
– |
Engine lifespan, km (miles)
-Official information
-Real |
300,000
300,000+ (185,000+) |
Tuning, HP
-Max HP
-No life span loss |
300+
– |
| The engine is installed in |
Toyota AE86
Toyota Avensis
Toyota Carina
Toyota Carina E
Toyota Celica
Toyota Corolla
Toyota Corona
Toyota MR2
Toyota Corolla Ceres
Toyota Corolla Levin
Toyota Corolla Spacio
Toyota Sprinter
Toyota Sprinter Carib
Toyota Sprinter Marino
Toyota Sprinter Trueno |
