Edelbrock 416 C.I.D. 602 HP Long Block Crate Engines for GM LS 46736
Couldn't load pickup availability
Guarantee safe checkout
Edelbrock 416 C.I.D. 602 HP Long Block Crate Engines for GM LS 46736
$11,500.00
Edelbrock 416 C.I.D. 602 HP Long Block Crate Engine for GM LS (46736) – Extreme LS Performance!
Unleash high-revving LS power with the Edelbrock 416 C.I.D. 602 HP Crate Engine!
The Edelbrock 416 C.I.D. 602 HP Long Block Crate Engine (46736) is engineered for track-ready horsepower and modern EFI performance. Built on a precision-machined aluminum LS block, this 6.8L powerhouse is equipped with high-flow aluminum cylinder heads, a custom Edelbrock hydraulic roller camshaft, and a Pro-Flo XT multi-point fuel injection system. Designed to handle high-RPM abuse while maintaining streetable driveability, this engine is ideal for high-performance street and strip applications.
A high-horsepower LS crate engine built for modern performance dominance!
Requires compatible fuel system, exhaust, and tuning for optimal performance.
What’s Included in the Edelbrock 416 C.I.D. Crate Engine?
Fully Assembled 416 C.I.D. LS-Based V8 Engine – Built for modern high-performance applications Pro-Flo XT Multi-Point EFI System with Throttle Body – Provides optimized fuel delivery and precise throttle response High-Flow Aluminum Cylinder Heads – Enhances airflow, combustion efficiency, and cooling Hydraulic Roller Camshaft & Valvetrain – Delivers smooth high-RPM performance Factory-Installed Oil Pan & Timing Cover – Ensures seamless operation and longevity Complete Ignition & Wiring Harness – Designed for plug-and-play EFI tuning
EXCLUDES exhaust system, air cleaner, spark plugs, fuel pump, and flywheel.
Technical Specifications
| Feature | Details |
|---|---|
| Brand | Edelbrock |
| Manufacturer’s Part # | 46736 |
| Product Type | Crate Engine |
| Summit Racing Part # | EDL-46736 |
| Crate Engine Family | Chevy LS |
| Actual Displacement | 6.8L / 416 C.I.D |
| Horsepower Output | 602 HP |
| Assembled? |
Yes |
| Engine Block Material | Aluminum |
| Cylinder Head Material | Aluminum |
| Engine Balance | Internal/External |
| Compression Ratio | 11.2:1 |
| Camshaft Type | Hydraulic Roller |
| Rear Main Seal Style | 1-Piece |
| Induction System | Fuel Injection |
| Intake Manifold Included? |
Yes |
| Throttle Body Included? |
Yes |
| Distributor Included? |
 No |
| Oil Pan Included? |
Yes |
| Valve Covers Included? |
Yes |
| Timing Cover Included? |
Yes |
| Water Pump Included? |
Yes |
| Harmonic Balancer Included? |
Yes |
| Flexplate Included? |
No |
| Flywheel Included? |
No |
| Air Cleaner Included? |
No |
| Spark Plugs Included? |
No |
| Spark Plug Wires Included? |
No |
| Computer Included? |
Yes |
| Wiring Harness Included? |
Yes |
| Supercharger Included? |
No |
| Quantity | Sold Individually |
Designed for maximum horsepower, track-ready performance, and modern LS swaps!
